VDSL Stats - Whats yours?

Simon Gruber Says

PeadarB wrote: »

I think the Actual INP increases to 29 or 30 symbols when vectoring is enabled.

Looks like it hasn't happened yet. I may get another bump in speed so when it is enabled. My attenuation seems a little bit high for my distance to the cab compared to others on here though.

lmimmfn

PeadarB wrote: »

I think the Actual INP increases to 29 or 30 symbols when vectoring is enabled.

not necessarily, i got the INP increase but vectoring wasnt enabled for about 4 months afterwards, i.e the can do the INP change and vectoring together as has happened for some of the cabinets or seperately.

ElNino

PeadarB wrote: »

I think the Actual INP increases to 29 or 30 symbols when vectoring is enabled.

Thanks for that. I assumed that vectoring hadn't been enabled on my cabinet as I was still on the 70Mbps profile. However after reading your post I realized that vectoring was in fact enabled so I just rang Eircom and got bumped up to 100Mbps within 5 minutes. I thought the upgrades were supposed to happen automatically once a month but that didn't happen in my case.

Before

VDSL Training Status: Showtime
Mode: VDSL2 Annex B
VDSL Profile: Profile 17a
Traffic Type: PTM Mode
Link Uptime: 49 days: 17 hours: 2 minutes
============================================================================
VDSL Port Details Upstream Downstream
Line Rate: 19.670 Mbps 71.678 Mbps
Actual Net Data Rate: 19.671 Mbps 71.679 Mbps
Trellis Coding: ON ON
SNR Margin: 10.8 dB 23.4 dB
Actual Delay: 0 ms 0 ms
Transmit Power: -14.3 dBm 13.2 dBm
Receive Power: -24.7 dBm 0.3 dBm
Actual INP: 29.0 symbols 30.0 symbols
Total Attenuation: 10.1 dB 12.8 dB
Attainable Net Data Rate: 22.949 Mbps 119.292 Mbps
============================================================================
VDSL Band Status U0 U1 U2 U3 D1 D2 D3
Line Attenuation(dB): 2.5 13.0 18.8 N/A 7.8 17.2 26.9
Signal Attenuation(dB): 2.5 11.6 17.7 N/A 10.1 17.0 26.9
SNR Margin(dB): 10.6 10.9 10.8 N/A 23.9 23.8 23.8
Transmit Power(dBm):-25.2 -16.8 -19.9 N/A 9.9 7.7 7.0
============================================================================

and after

VDSL Training Status: Showtime
Mode: VDSL2 Annex B
VDSL Profile: Profile 17a
Traffic Type: PTM Mode
Link Uptime: 0 day: 0 hour: 0 minute
============================================================================
VDSL Port Details Upstream Downstream
Line Rate: 20.477 Mbps 102.395 Mbps
Actual Net Data Rate: 20.478 Mbps 102.396 Mbps
Trellis Coding: ON ON
SNR Margin: 9.2 dB 10.3 dB
Actual Delay: 0 ms 0 ms
Transmit Power: -14.9 dBm 13.3 dBm
Receive Power: -25.2 dBm 0.6 dBm
Actual INP: 29.0 symbols 29.0 symbols
Total Attenuation: 10.3 dB 12.6 dB
Attainable Net Data Rate: 22.242 Mbps 107.836 Mbps
============================================================================
VDSL Band Status U0 U1 U2 U3 D1 D2 D3
Line Attenuation(dB): 2.5 12.8 18.7 N/A 7.7 17.2 26.8
Signal Attenuation(dB): 2.5 12.2 17.5 N/A 10.0 17.0 26.7
SNR Margin(dB): 9.2 9.3 9.2 N/A 10.3 10.3 10.2
Transmit Power(dBm):-25.4 -17.0 -20.2 N/A 10.1 7.9 6.9

foggy_lad

Vodafone Upload speeds getting worse. They are not prepared to admit there is any problem or issue and instead tell me they will release me from contract so I can move to another provider, They are obviously well aware that no other operator offers the same service for €35/month.

swoofer

how do I check the INP figure in the VF modem?

Dcully

ElNino wrote: »

Thanks for that. I assumed that vectoring hadn't been enabled on my cabinet as I was still on the 70Mbps profile. However after reading your post I realized that vectoring was in fact enabled so I just rang Eircom and got bumped up to 100Mbps within 5 minutes. I thought the upgrades were supposed to happen automatically once a month but that didn't happen in my case.

Before


and after

I spoke to online support friday to get this done and they said their system says im on 50/20 profile yet my stats and speedtests state ive been on 70/20 since i got efibre a few months back, the nest result is they have dropped me back to 50/20 without my asking.
FFS i make a call to get speeds increased closer to to what my stats suggest ie 100 mb im only a few meters from cabinet and this is the outcome.

nilhg

Strange one this morning, power went overnight and only came back ip an hour or so ago, modem synced at the highest speeds I've seen since we got the VDSL, in fact it's syncing at a higher rate than the attainable it's reporting....



Line standard VDSL2
Channel type
None
Downstream line rate (kbit/s) 44337
Upstream line rate (kbit/s) 9576
Downstream attainable data rate(kbit/s) 44304
Upstream attainable data rate(kbit/s) 9373
Downstream SNR (dB) 9.6
Upstream SNR (dB) 8.1
Downstream line attenuation (dB) 18.9
Upstream line attenuation (dB) 6.4
Downstream output power (dBmV) 12.4
Upstream output power (dBmV) 7.2
Downstream CRC 0
Upstream CRC 0
Downstream FEC 1975
Upstream FEC 36

ED E

It trained high as it was probably one of the first to come on thus low crosstalk at the time. Reboot and itll go back to normal.

badboybubby

Was told by the Vodafone sales guy I'd be put on 70/20.the engineer who installed the socket said I should get about 70 or 80 megs down.rang em today and they won't raise my profile from 50/20.they wouldn't give a reason.

Getting about 47 down 19 up wired .
Any idea why they won't raise it?

Line standard VDSL2
Channel type None
Downstream line rate (kbit/s) 51198
Upstream line rate (kbit/s) 20478
Downstream attainable data rate(kbit/s) 105988
Upstream attainable data rate(kbit/s) 25324
Downstream SNR (dB) 25.8
Upstream SNR (dB) 11.4
Downstream line attenuation (dB) 9
Upstream line attenuation (dB) 2.5
Downstream output power (dBmV) 12.9
Upstream output power (dBmV) -12.6
Downstream CRC 0
Upstream CRC 0
Downstream FEC 37
Upstream FEC 179

Dcully

badboybubby wrote: »

Was told by the Vodafone sales guy I'd be put on 70/20.the engineer who installed the socket said I should get about 70 or 80 megs down.rang em today and they won't raise my profile from 50/20.they wouldn't give a reason.

Getting about 47 down 19 up wired .
Any idea why they won't raise it?

Line standard VDSL2
Channel type None
Downstream line rate (kbit/s) 51198
Upstream line rate (kbit/s) 20478
Downstream attainable data rate(kbit/s) 105988
Upstream attainable data rate(kbit/s) 25324
Downstream SNR (dB) 25.8
Upstream SNR (dB) 11.4
Downstream line attenuation (dB) 9
Upstream line attenuation (dB) 2.5
Downstream output power (dBmV) 12.9
Upstream output power (dBmV) -12.6
Downstream CRC 0
Upstream CRC 0
Downstream FEC 37
Upstream FEC 179

Pretty sure they are waiting for a prequal to be done on your cab ,im waiting on prequal to be done on my cab almost 3 months now.
Like yourself my stats are very good and attainable rate is predicted to be in the 100mb range,

foggy_lad

Vodafone seem to have a funny way of dividing up bandwidth between customers, my line is well capable of 18+ Mbps yet they claim the best I can have is 12Mbps or more recently 8Mbps.

My upload speed is brilliant on a wired connection and only restricted by wireless cards in my laptops but the upload which should be 18.4Mbps is falling all the time. They have done several checks on the line but have said there is no fault on the line. They claim my line is not capable of faster upload even though other customers the same distance from their cabinets are getting proper speeds!

As far as I know they have not investigated or answered my concerns about the cable ducting under the footpath outside and the Eircom connection boxes being full of water for about 2 years due to burst water pipes.
Wireless
and Wired

badboybubby

Dcully wrote: »

Pretty sure they are waiting for a prequal to be done on your cab ,im waiting on prequal to be done on my cab almost 3 months now.
Like yourself my stats are very good and attainable rate is predicted to be in the 100mb range,

Thanks,sounds like that might be it alright.

ShodenMcClane

Hey everyone,

I have a small bit of a conundrum. I have Efibre, recently went from a 35/20 profile to a 50/20 profile and my speeds have stayed the same at around 30mbps on wired tests even though my line rate and Actual Net Data Rate have gone up the right amounts.

Anyone have any ideas?

Cheers in advance. Below are my stats:

VDSL Training Status: Showtime
Mode: VDSL2 Annex B
VDSL Profile: Profile 17a
Traffic Type: PTM Mode
Link Uptime: 0 day: 0 hour: 12 minutes
============================================================================
VDSL Port Details Upstream Downstream
Line Rate: 16.382 Mbps 51.197 Mbps
Actual Net Data Rate: 16.383 Mbps 51.198 Mbps
Trellis Coding: ON ON
SNR Margin: 17.9 dB 16.9 dB
Actual Delay: 0 ms 0 ms
Transmit Power: 2.6 dBm 12.4 dBm
Receive Power: -15.3 dBm -7.5 dBm
Actual INP: 29.0 symbols 29.0 symbols
Total Attenuation: 17.8 dB 19.9 dB
Attainable Net Data Rate: 31.181 Mbps 75.252 Mbps
============================================================================
VDSL Band Status U0 U1 U2 U3 D1 D2 D3
Line Attenuation(dB): 3.3 28.4 33.4 N/A 12.3 30.6 45.3
Signal Attenuation(dB): 3.3 27.3 32.6 N/A 15.6 30.6 45.3
SNR Margin(dB): 18.1 18.1 17.9 N/A 16.9 16.9 16.8
Transmit Power(dBm):-12.3 - 2.7 0.8 N/A 7.9 8.0 6.7
============================================================================

Dcully

Dcully wrote: »

I spoke to online support friday to get this done and they said their system says im on 50/20 profile yet my stats and speedtests state ive been on 70/20 since i got efibre a few months back, the nest result is they have dropped me back to 50/20 without my asking.
FFS i make a call to get speeds increased closer to to what my stats suggest ie 100 mb im only a few meters from cabinet and this is the outcome.

Back to normal thankfully.
Id be very wary about ringing to get profile changed again.

swoofer

I know the feeling, ring and get told there is a fault, instead of upping the profile, sent out an eircom engineer = no fault. = will not ring them again. awful

CutWeldDrive

does this look right,
i feel i should be getting higher speeds or am i wrong.


============================================================================
VDSL Training Status: Showtime
Mode: VDSL2 Annex B
VDSL Profile: Profile 17a
Traffic Type: PTM Mode
Link Uptime: 17 days: 6 hours: 9 minutes
============================================================================
VDSL Port Details Upstream Downstream
Line Rate: 4.220 Mbps 30.684 Mbps
Actual Net Data Rate: 4.221 Mbps 30.685 Mbps
Trellis Coding: ON ON
SNR Margin: 9.0 dB 8.3 dB
Actual Delay: 0 ms 0 ms
Transmit Power: 7.2 dBm 10.3 dBm
Receive Power: -8.6 dBm -16.2 dBm
Actual INP: 29.0 symbols 30.0 symbols
Total Attenuation: 15.9 dB 26.6 dB
Attainable Net Data Rate: 4.468 Mbps 32.732 Mbps

ED E

You're right where you should be considering the current line "quality". Profile is just below attains and SNRs are at ok but not super levels.


If you're over 1200m from the cabinet then its likely correct, if you're closer then it could be indicative of a fault.

brianeoc

I just got connected with Sky fibre this week. The sky modem stats are fairly basic but I've posted them below for public consumption.


Connection Speed is Down = 92156 Kbps Up = 20478kbps
Line Attenuation Down = 12.6 dB Up = 0
Noise Margin Down = 20.6 dB Up = 12.12dB


Yesterday evening at 7pm I was getting 18mb down and 17mb up.
At 10pm I was getting 12mb down and 17mb up.
At 12pm this was 26mb down and 19mb up
And at 8:15am this morning I was getting 40mb down and 19mb up.

Dermot McDonnell

Wanted to include this post from another thread here:


Best xDSL stats seen to date. This from an unlocked F1000 with latest firmware in Belfield, Dublin 4. Thanks to Lee K for his numbers.

=======
VDSL Port Details Upstream Downstream

Line Rate: 20.477 Mbps 102.395 Mbps

Actual Net Data Rate: 20.478 Mbps 102.396 Mbps

Trellis Coding: ON ON

SNR Margin: 11.3 dB 18.5 dB

Actual Delay: 0 ms 0 ms

Transmit Power: -22.8 dBm 13.3 dBm

Receive Power: -27.4 dBm 7.0 dBm

Actual INP: 29.0 symbols 29.0 symbols

Total Attenuation: 4.7 dB 6.1 dB

Attainable Net Data Rate: 25.320 Mbps 136.634 Mbps

---

VDSL Band Status U0 U1 U2 U3 D1 D2 D3

Line Attenuation(dB): 1.0 5.9 7.4 N/A 3.9 8.6 14.4

Signal Attenuation(dB): 1.0 5.4 6.6 N/A 4.0 8.5 14.4

SNR Margin(dB): 11.4 11.4 11.3 N/A 18.6 18.4 18.5

Transmit Power(dBm):-32.3 -24.0 -30.9 N/A 10.1 7.8 7.0

foggy_lad

Just want to update on an issue which I had with my upload speed with my Vodafone Fibre where I was getting max 11-12mbps instead of the 18-19mbps I should have been getting.

For the last number of days at least my upload speed has been up at 18mbps and appears to be quite steady, also on the Speedtest.net test the line is now rated as being A where before it was always B or B+ or A-.

These results are with a wired connection using 500mpbs homeplugs.





Hopefully this is not just a temporary improvement like before when it was fixed for almost a month.

Thanks to all that tried to help before, I probably would have gone mad without the help:D:pac::eek::P

jca

foggy_lad wrote: »

Just want to update on an issue which I had with my upload speed with my Vodafone Fibre where I was getting max 11-12mbps instead of the 18-19mbps I should have been getting.

For the last number of days at least my upload speed has been up at 18mbps and appears to be quite steady, also on the Speedtest.net test the line is now rated as being A where before it was always B or B+ or A-.

These results are with a wired connection using 500mpbs homeplugs.





Hopefully this is not just a temporary improvement like before when it was fixed for almost a month.

Thanks to all that tried to help before, I probably would have gone mad without the help:D:pac::eek::P

Did you do anything or did it just right itself?

foggy_lad

jca wrote: »

Did you do anything or did it just right itself?

I did nothing and vodafone did even less!

They were so bad they even released me from my 18month contract just two months in because they were unable to find the fault. Speed from the socket in my kitchen measured by several technicians was showing the full 20mbps yet speed out of their modems in use was just 11mbps but for three weeks in october/november the speed jumped to same as it is now. An obvious sign that there was a fault or that vodafine are somehow managing the upload speeds for some reason?

godskitchen

Thought I'd resurrect my own thread with a quick question.....

Have any of you experienced a connection that would connect at a higher rate than the maximum stated obtainable rate?

It's a strange one. The connection seems fine and is running a number of services.

peking97

Yes. I've the same situation here.

ED E

Gotta be a bug in the Huawei firmware.

godskitchen

ED E wrote: »

Gotta be a bug in the Huawei firmware.

The one in my instance is a F1000

dazdrog

Still cant get put onto a rate adaptive profile as vodafone claim cab is locked to 50mb

notahappycamper

dazdrog wrote: »

Still cant get put onto a rate adaptive profile as vodafone claim cab is locked to 50mb

Bull**** that Vodafone is telling you. The real reason I bet is that they do not like to give you the higher rate as their "target" SNR is 12 I think. Ask to speak to someone in 2nd level support (Vic or Barry)and tell them to do it for a week. If the line stays stable great if not well then it will need to be reduced. Alao, your line appears very stable with no CRC errors up or down for a month and counting and low FEC errors for a month.

jca

notahappycamper wrote: »

Bull**** that Vodafone is telling you. The real reason I bet is that they do not like to give you the higher rate as their "target" SNR is 12 I think. Ask to speak to someone in 2nd level support (Vic or Barry)and tell them to do it for a week. If the line stays stable great if not well then it will need to be reduced. Alao, your line appears very stable with no CRC errors up or down for a month and counting and low FEC errors for a month.

I was on rate adaptive when I was connected first, they then put me on a stable profile while I had the free trial of eVision. When I got rid of eVision they eventually put me back on R.A. However my speeds don't reflect this, the unlocked F1000 says I'm on 70/20, Eircom say I'm on 70/20 but I can never get higher than 45/15 on speed tests. My samknows box shows 45/15 continuously as well. I've given up at this stage.

dazdrog

notahappycamper wrote: »

Bull**** that Vodafone is telling you. The real reason I bet is that they do not like to give you the higher rate as their "target" SNR is 12 I think. Ask to speak to someone in 2nd level support (Vic or Barry)and tell them to do it for a week. If the line stays stable great if not well then it will need to be reduced. Alao, your line appears very stable with no CRC errors up or down for a month and counting and low FEC errors for a month.

yeah i know that mate even when fiber launced first in my area i had magnet with a sync speed of 50/20 (before any crosstalk reducing gear was implemented) with snr's of 6db, perfectly stable.

i may try them again tomorrow as its been 4 or 5 months since last try. i am on a extended cab tho if that helps, as far as i know its not vectored
