USB DVB T2 Tuner - for enigma 2 box

zbluebirdz

I'm looking for a USB DVB T2 tuner for an enigma 2 box (technomate). The box doesn't have a DVB T/T2 tuner, nor can one be fitted to it. I plan to fit a saorsat lnb to my dish at a later date.

In the meantime, I'd like to add a USB DVB T2 tuner to my new box.

Would a PS3 PlayTV tuner still work on 2017 enigma box? If not, can anyone recommend one that is < €30?

swoofer

it would and its a dual tuner into the bargain, you just need to dowload the correct driver, its db0700 then reboot box with tuner plugged in etc.

tsue921i8wljb3

swoofer wrote: »

it would and its a dual tuner into the bargain, you just need to dowload the correct driver, its db0700 then reboot box with tuner plugged in etc.

It's not T2 though. Although if it is only for Saorview DVB-T is all you need and the PlayTV should work fine. T2 would be needed for UK Freeview HD channels.

soporific

I've (unfortunately) had a good bit of experience with different usb dvb tuners on enigma2. i started with an august T210 (which is a rebranded Geniatech/Mygica T220), which I read had drivers for enigma2. It didn't. Next i tried the sony Playtv to take advanatge of the two tuners. I used the dib0700 driver - but only one tuner appeared available (even though both worked on pc and kodi) Next I tried the astrometa dvb-t2/ dab/fm stick (available for 16 euro delivered from china on ebay). I still haven't got dvb-t2 working (you have to rename adapters according to one thread I found) but dvb-t works ok. I should have just bought a 292e nanoStick in the beginning! It has good dvb-t2 drivers and is very solid according to reports.

hadoken13

I just got a Technomate TM-twin with a astrometa USB DVB-T tuner, but I can't get the box to recognise the tuner. My laptop finds it so the tuner is working. I've tried installing the driver (dvb-usb-rtl2832 according to freetv) but the box still won't pick up the device. I've flashed the latest openpli image, reinstalled the driver and still nothing. Any ideas?

soporific

i had no problem setting up the astrometa stick. I donwloaded the same driver as you from the feeds, rebooted, and there it was. I'm using Openatv 6.0 on an edision os mini.

hadoken13

soporific wrote: »

i had no problem setting up the astrometa stick. I donwloaded the same driver as you from the feeds, rebooted, and there it was. I'm using Openatv 6.0 on an edision os mini.

I've contacted the seller and they are testing a few other images, openatv and another one. They were meant to get back to me but never did. I might try openatv myself.

Johnboy1951

hadoken13 wrote: »

I just got a Technomate TM-twin with a astrometa USB DVB-T tuner, but I can't get the box to recognise the tuner. My laptop finds it so the tuner is working. I've tried installing the driver (dvb-usb-rtl2832 according to freetv) but the box still won't pick up the device. I've flashed the latest openpli image, reinstalled the driver and still nothing. Any ideas?

Just wondering if that is the correct driver ...... maybe dvb-usb-rtl28xxU might be the one required?

STB.

hadoken13 wrote: »

I just got a Technomate TM-twin with a astrometa USB DVB-T tuner, but I can't get the box to recognise the tuner. My laptop finds it so the tuner is working. I've tried installing the driver (dvb-usb-rtl2832 according to freetv) but the box still won't pick up the device. I've flashed the latest openpli image, reinstalled the driver and still nothing. Any ideas?

Reboot your box. Do a hard reboot - ie turn off and on at the switch.

If that doesnt work you can do telnet, login to the box and a dmesg | grep dvb to see whats going on.

hadoken13

STB. wrote: »

Reboot your box. Do a hard reboot - ie turn off and on at the switch.

If that doesnt work you can do telnet, login to the box and a dmesg | grep dvb to see whats going on.

Been away from Boards so forgot to reply.

The seller contacted Technomate who said the USB tuner doesn't work for the device yet as there is no driver available for it. I am returning the driver this week.

STB.

hadoken13 wrote: »

Been away from Boards so forgot to reply.

The seller contacted Technomate who said the USB tuner doesn't work for the device yet as there is no driver available for it. I am returning the driver this week.

There isnt drivers for a lot of USB devices!

Anyway who told you there was no driver for it. DVB-T works on these as there is a linux driver for T, just not T2 or C. They are the REALTEK SDR family.

You are using OpenPLi. They got it working. You just need to do a little bit of editing....

https://forums.openpli.org/topic/35710-astrometa-dvb-tt2c-mn88472mn88473/page-5

hadoken13

Thanks mate. We might look to picking up a new tuner later as we returned the other one.

STB. wrote: »

There isnt drivers for a lot of USB devices!

Anyway who told you there was no driver for it. DVB-T works on these as there is a linux driver for T, just not T2 or C. They are the REALTEK SDR family.

You are using OpenPLi. They got it working. You just need to do a little bit of editing....

https://forums.openpli.org/topic/35710-astrometa-dvb-tt2c-mn88472mn88473/page-5

STB.

hadoken13 wrote: »

Thanks mate. We might look to picking up a new tuner later as we returned the other one.

I see that you live not too far from freesat down in Marino. Yes they should have the requisite stick. Bring the box down and they will do it for you I'm sure. Thats their business.

Outside of that there is no secret to how the drivers are installed for these sticks. You go to the plugin menu and download the driver for the usb stick you bought (plugins, download plugins, drivers). There are many chipsets supported. All the ones that start dvb-usb-xxxx.



Some have two tuner capability such as the playtv devices. You will also need an MCX to RF cable which junctions the stick to your aerial connection on the wall or indoor aerial. The little aerials that come with USB sticks are useless.

soporific

I finally bought a 292e nanostick. I've been using the sonyplaytv tuner for the last few months and I don't think I ever recorded an Irish TV program without breakups or errors. Wow, the 292e is so much better. So far, no breakups in any Irish recordings. It's more expensive than getting a sonyplayTv but so far on my dodgy aerial it is proving a worthwhile investment.

gkp1

Looking to add a second terrestrial tuner (USB) to a Formuler box (enigma2), anyone know if this would work?
Official Xbox One Digital TV Tuner (Xbox One) by Microsoft

http://amzn.eu/6wEf512

Ten Pin

Official Xbox One Digital TV Tuner (Xbox One) by Microsoft

Don't know the answer about enigma2 support but they are in GameStop for a tenner
https://www.gamestop.ie/Xbox One/Games/55762

soporific

I had a quick look at the linux page for this tuner:
https://www.linuxtv.org/wiki/index.php/Xbox_One_Digital_TV_Tuner

and it seems that it has the dib0700 module which has a driver in enigma

the demodulator (Panasonic MN88472) might prove a problem

Anybody have any ideas?

STB.

soporific wrote: »

I had a quick look at the linux page for this tuner:
https://www.linuxtv.org/wiki/index.php/Xbox_One_Digital_TV_Tuner

and it seems that it has the dib0700 module which has a driver in enigma

the demodulator (Panasonic MN88472) might prove a problem

Anybody have any ideas?

The driver is already compiled for E2 for that chipset.

Its in Plugins, under Drivers, dvb-usb-dib0700. Install. Reboot.

soporific

I couldn't resist nipping into Gamestop and getting one of these 9.99 tuners. well it works perfectly out of the box with librelec kodi (once you enable it in TVheadend) and that will be what I will use it for! (Thanks for the tip Ten Pin!)

But no luck so far with either win10 or enigma. I have the dib0700 downloaded from plugins (and playtv tuner works fine) but the Xbox one tuner is not recognised. I also checked to see if the MN88472 module was in lib/firmware. Theoretically (to my limited knoweldge) it should work - but no luck.

oh well, it's still a cheap dvb-t2 tuner for kodi!

STB.

soporific wrote: »

But no luck so far with either win10 or enigma. I have the dib0700 downloaded from plugins (and playtv tuner works fine) but the Xbox one tuner is not recognised. I also checked to see if the MN88472 module was in lib/firmware. Theoretically (to my limited knoweldge) it should work - but no luck.

oh well, it's still a cheap dvb-t2 tuner for kodi!

Telnet into the e2 box.

Type lsusb (this is to see if its seeing the usb device)

and then dmesg will give you the error and the firmware it is expecting.

You then need to stick the firmware in the lib/firmware directory. The .fw for that may be on the internet somewhere - it might be the one linked earlier

soporific

Hi STB

I've tried those commands

root@osmini:~# lsusb
Bus 001 Device 001: ID 1d6b:0002
Bus 001 Device 002: ID 045e:02d5
Bus 002 Device 001: ID 1d6b:0001

So ID 045e:02d5 (the xbox one tv tuner) is recognised ...but...when i do dmesg, i cant work out what's relevant. here's the longish printout:

root@osmini:~# dmesg
Linux version 4.11.0 (oe1@build3) (gcc version 6.3.0 (GCC) ) #2 SMP Sat Nov 18 12:52:25 CET 2017
CPU0 revision is: 0002a065 (Broadcom BMIPS4380)
FPU revision is: 00130001
MIPS: machine is Broadcom BCM97362SVMB
Determined physical RAM map:
memory: 10000000 @ 00000000 (usable)
Primary instruction cache 32kB, VIPT, 2-way, linesize 64 bytes.
Primary data cache 64kB, 4-way, VIPT, cache aliases, linesize 64 bytes
This processor doesn't support highmem. -262144k highmem ignored
Zone ranges:
Normal [mem 0x0000000000000000-0x000000000fffffff]
HighMem empty
Movable zone start for each node
Early memory node ranges
node 0: [mem 0x0000000000000000-0x000000000fffffff]
Initmem setup node 0 [mem 0x0000000000000000-0x000000000fffffff]
On node 0 totalpages: 65536
free_area_init_node: node 0, pgdat 80a6d200, node_mem_map 8100b000
Normal zone: 512 pages used for memmap
Normal zone: 0 pages reserved
Normal zone: 65536 pages, LIFO batch:15
percpu: Embedded 16 pages/cpu @8120e000 s34192 r8192 d23152 u65536
pcpu-alloc: s34192 r8192 d23152 u65536 alloc=16*4096
pcpu-alloc: [0] 0 [0] 1
Built 1 zonelists in Zone order, mobility grouping on. Total pages: 65024
Kernel command line: console=ttyS0,115200 ubi.mtd=rootfs root=ubi0:rootfs rootfstype=ubifs
PID hash table entries: 1024 (order: 0, 4096 bytes)
Dentry cache hash table entries: 32768 (order: 5, 131072 bytes)
Inode-cache hash table entries: 16384 (order: 4, 65536 bytes)
Memory: 248396K/262144K available (8569K kernel code, 335K rwdata, 1712K rodata, 320K init, 303K bss, 13748K reserved, 0K cma-reserved, 0K highmem)
SLUB: HWalign=128, Order=0-3, MinObjects=0, CPUs=2, Nodes=1
Hierarchical RCU implementation.
Build-time adjustment of leaf fanout to 32.
RCU restricting CPUs from NR_CPUS=4 to nr_cpu_ids=2.
RCU: Adjusting geometry for rcu_fanout_leaf=32, nr_cpu_ids=2
NR_IRQS:128
irq_bcm7038_l1: registered BCM7038 L1 intc (mem: 0xb0411400, IRQs: 96)
irq_brcmstb_l2: registered L2 intc (mem: 0xb0403000, parent irq: 56)
irq_bcm7120_l2: registered BCM7120 L2 intc (mem: 0xb0406600, parent IRQ(s): 2)
irq_bcm7120_l2: registered BCM7120 L2 intc (mem: 0xb0408b80, parent IRQ(s): 3)
irq_brcmstb_l2: registered L2 intc (mem: 0xb0408440, parent irq: 58)
irq_brcmstb_l2: registered L2 intc (mem: 0xb0411000, parent irq: 38)
irq_brcmstb_l2: registered L2 intc (mem: 0xb0411d00, parent irq: 39)
clocksource: MIPS: mask: 0xffffffff max_cycles: 0xffffffff, max_idle_ns: 5086541108 ns
sched_clock: 32 bits at 250 Hz, resolution 4000000ns, wraps every 8589934590000000ns
Console: colour dummy device 80x25
Calibrating delay loop... 749.56 BogoMIPS (lpj=1499136)
pid_max: default: 32768 minimum: 301
Mount-cache hash table entries: 1024 (order: 0, 4096 bytes)
Mountpoint-cache hash table entries: 1024 (order: 0, 4096 bytes)
smp: Bringing up secondary CPUs ...
SMP: Booting CPU1...
Primary instruction cache 32kB, VIPT, 2-way, linesize 64 bytes.
Primary data cache 64kB, 4-way, VIPT, cache aliases, linesize 64 bytes
CPU1 revision is: 0002a065 (Broadcom BMIPS4380)
FPU revision is: 00130001
Synchronize counters for CPU 1: done.
SMP: CPU1 is running
smp: Brought up 1 node, 2 CPUs
devtmpfs: initialized
clocksource: jiffies: mask: 0xffffffff max_cycles: 0xffffffff, max_idle_ns: 7645041785100000 ns
futex hash table entries: 512 (order: 4, 65536 bytes)
NET: Registered protocol family 16
SCSI subsystem initialized
libata version 3.00 loaded.
usbcore: registered new interface driver usbfs
usbcore: registered new interface driver hub
usbcore: registered new device driver usb
Linux video capture interface: v2.00
Advanced Linux Sound Architecture Driver Initialized.
Bluetooth: Core ver 2.22
NET: Registered protocol family 31
Bluetooth: HCI device and connection manager initialized
Bluetooth: HCI socket layer initialized
Bluetooth: L2CAP socket layer initialized
Bluetooth: SCO socket layer initialized
clocksource: Switched to clocksource MIPS
FS-Cache: Loaded
NET: Registered protocol family 2
TCP established hash table entries: 2048 (order: 1, 8192 bytes)
TCP bind hash table entries: 2048 (order: 2, 16384 bytes)
TCP: Hash tables configured (established 2048 bind 2048)
UDP hash table entries: 256 (order: 1, 8192 bytes)
UDP-Lite hash table entries: 256 (order: 1, 8192 bytes)
NET: Registered protocol family 1
RPC: Registered named UNIX socket transport module.
RPC: Registered udp transport module.
RPC: Registered tcp transport module.
RPC: Registered tcp NFSv4.1 backchannel transport module.
workingset: timestamp_bits=30 max_order=16 bucket_order=0
FS-Cache: Netfs 'nfs' registered for caching
NFS: Registering the id_resolver key type
Key type id_resolver registered
Key type id_legacy registered
nfs4filelayout_init: NFSv4 File Layout Driver Registering...
Installing knfsd (copyright (C) 1996 okir@monad.swb.de).
FS-Cache: Netfs 'cifs' registered for caching
Key type cifs.spnego registered
fuse init (API version 7.26)
Block layer SCSI generic (bsg) driver version 0.4 loaded (major 253)
io scheduler noop registered
io scheduler deadline registered
io scheduler cfq registered (default)
io scheduler mq-deadline registered
brcm-gisb-arb 10400000.gisb-arb: registered mem: b0400000, irqs: 104, 105
brcm-sata-phy 10180100.sata-phy: registered 2 port(s)
random: fast init done
brcmstb-gpio 10406500.gpio: Registered 5 banks (GPIO(s): 0-159)
brcmstb-gpio 10408c00.gpio: Registered 3 banks (GPIO(s): 160-255)
Serial: 8250/16550 driver, 4 ports, IRQ sharing disabled
console [ttyS0] disabled
10406800.serial: ttyS0 at MMIO 0x10406800 (irq = 69, base_baud = 5062500) is a 16550A
console [ttyS0] enabled
10406840.serial: ttyS1 at MMIO 0x10406840 (irq = 70, base_baud = 5062500) is a 16550A
10406880.serial: ttyS2 at MMIO 0x10406880 (irq = 71, base_baud = 5062500) is a 16550A
loop: module loaded
brcm-ahci 10181000.sata: controller can't do NCQ, turning off CAP_NCQ
brcm-ahci 10181000.sata: masking port_map 0x3 -> 0x3
brcm-ahci 10181000.sata: SSS flag set, parallel bus scan disabled
brcm-ahci 10181000.sata: AHCI 0001.0300 32 slots 2 ports 6 Gbps 0x3 impl platform mode
brcm-ahci 10181000.sata: flags: sntf stag pm clo slum part
scsi host0: brcm-ahci
scsi host1: brcm-ahci
ata1: SATA max UDMA/133 mmio [mem 0x10181000-0x10181a9b] port 0x100 irq 94
ata2: SATA max UDMA/133 mmio [mem 0x10181000-0x10181a9b] port 0x180 irq 94
brcm-ahci 10181000.sata: Broadcom AHCI SATA3 registered
nand: device found, Manufacturer ID: 0x01, Chip ID: 0xdc
nand: AMD/Spansion S34ML04G2
nand: 512 MiB, SLC, erase size: 128 KiB, page size: 2048, OOB size: 128
brcmstb_nand 10412800.nand: detected 512MiB total, 128KiB blocks, 2KiB pages, 32B OOB, 8-bit, BCH-4
Bad block table found at page 262080, version 0x01
Bad block table found at page 262016, version 0x01
3 ofpart partitions found on MTD device brcmnand.2
Creating 3 MTD partitions on "brcmnand.2":
0x000000000000-0x000000800000 : "kernel"
0x000000800000-0x000000c00000 : "splash"
0x000000c00000-0x00001fe00000 : "rootfs"
brcmstb_qspi 10410920.spi: using bspi-mspi mode
m25p80 spi32766.0: found mx25l3205d, expected m25p80
m25p80 spi32766.0: mx25l3205d (4096 Kbytes)
3 ofpart partitions found on MTD device spi32766.0
Creating 3 MTD partitions on "spi32766.0":
0x000000000000-0x0000000a0000 : "cfe"
0x0000000a0000-0x0000000b0000 : "nvram"
0x0000000b0000-0x0000000c0000 : "mac"
libphy: Fixed MDIO Bus: probed
bcmgenet 10430000.ethernet: failed to get enet clock
bcmgenet 10430000.ethernet: GENET 2.0 EPHY: 0x00b0
bcmgenet 10430000.ethernet: failed to get enet-wol clock
ata1: SATA link down (SStatus 0 SControl 300)
bcmgenet 10430000.ethernet: failed to get enet-eee clock
libphy: bcmgenet MII bus: probed
usbcore: registered new interface driver zd1201
ehci_hcd: USB 2.0 'Enhanced' Host Controller (EHCI) Driver
ehci-platform: EHCI generic platform driver
ehci-platform 10480300.usb: EHCI Host Controller
ehci-platform 10480300.usb: new USB bus registered, assigned bus number 1
ehci-platform 10480300.usb: irq 73, io mem 0x10480300
ehci-platform 10480300.usb: USB 2.0 started, EHCI 1.00
hub 1-0:1.0: USB hub found
hub 1-0:1.0: 2 ports detected
ohci_hcd: USB 1.1 'Open' Host Controller (OHCI) Driver
ohci-platform: OHCI generic platform driver
ata2: SATA link down (SStatus 0 SControl 300)
ohci-platform 10480400.usb: Generic Platform OHCI controller
ohci-platform 10480400.usb: new USB bus registered, assigned bus number 2
ohci-platform 10480400.usb: irq 74, io mem 0x10480400
hub 2-0:1.0: USB hub found
hub 2-0:1.0: 2 ports detected
usbcore: registered new interface driver uas
usbcore: registered new interface driver usb-storage
mousedev: PS/2 mouse device common for all mice
i2c /dev entries driver
brcmstb-i2c 10406200.i2c: upg_bsca@97500hz registered in interrupt mode
brcmstb-i2c 10406280.i2c: upg_bscb@97500hz registered in interrupt mode
brcmstb-i2c 10408980.i2c: upg_bscd@97500hz registered in interrupt mode
usbcore: registered new interface driver btusb
bmips-cpufreq: registered
sdhci: Secure Digital Host Controller Interface driver
sdhci: Copyright(c) Pierre Ossman
sdhci-pltfm: SDHCI platform and OF driver helper
sdhci-brcmstb 10410000.sdhci: Clock not found in Device Tree
mmc0: SDHCI controller on 10410000.sdhci [10410000.sdhci] using ADMA
hidraw: raw HID events driver (C) Jiri Kosina
usbcore: registered new interface driver usbhid
usbhid: USB HID core driver
NET: Registered protocol family 17
Bluetooth: HIDP (Human Interface Emulation) ver 1.2
Bluetooth: HIDP socket layer initialized
Key type dns_resolver registered
ubi0: attaching mtd2
mmc0: new high speed SDIO card at address 0001
usb 1-1: new high-speed USB device number 2 using ehci-platform
random: crng init done
ubi0: scanning is finished
ubi0: attached mtd2 (name "rootfs", size 498 MiB)
ubi0: PEB size: 131072 bytes (128 KiB), LEB size: 126976 bytes
ubi0: min./max. I/O unit sizes: 2048/2048, sub-page size 2048
ubi0: VID header offset: 2048 (aligned 2048), data offset: 4096
ubi0: good PEBs: 3984, bad PEBs: 0, corrupted PEBs: 0
ubi0: user volume: 1, internal volumes: 1, max. volumes count: 128
ubi0: max/mean erase counter: 10/3, WL threshold: 4096, image sequence number: 1161285828
ubi0: available PEBs: 0, total reserved PEBs: 3984, PEBs reserved for bad PEB handling: 80
ubi0: background thread "ubi_bgt0d" started, PID 84
ALSA device list:
No soundcards found.
UBIFS (ubi0:0): UBIFS: mounted UBI device 0, volume 0, name "rootfs", R/O mode
UBIFS (ubi0:0): LEB size: 126976 bytes (124 KiB), min./max. I/O unit sizes: 2048 bytes/2048 bytes
UBIFS (ubi0:0): FS size: 493809664 bytes (470 MiB, 3889 LEBs), journal size 9023488 bytes (8 MiB, 72 LEBs)
UBIFS (ubi0:0): reserved for root: 0 bytes (0 KiB)
UBIFS (ubi0:0): media format: w4/r0 (latest is w5/r0), UUID D5C9E3F1-B9B3-489D-BCF4-8002D63BA756, small LPT model
VFS: Mounted root (ubifs filesystem) readonly on device 0:13.
devtmpfs: mounted
Freeing unused kernel memory: 320K
This architecture does not have kernel memory protection.
fts260: loading out-of-tree module taints kernel.
fts260: module license 'Proprietary' taints kernel.
Disabling lock debugging due to kernel taint
dvbdev: DVB: registering new adapter (Broadcom BCM7xxx)
input: dreambox advanced remote control (native) as /devices/virtual/misc/brcmstb/input0
input: dreambox ir mouse as /devices/virtual/misc/brcmstb/input1
input: dreambox front panel as /devices/virtual/misc/brcmstb/input2
misc brcmstb: DVB: registering adapter 0 frontend 0 (Broadcom BCM73XX)...
misc brcmstb: DVB: registering adapter 0 frontend 1 (FTS-260 (Montage RS6000))...
Bluetooth: HCI UART driver ver 2.3
Bluetooth: HCI UART protocol H4 registered
Bluetooth: HCI UART protocol BCSP registered
Bluetooth: HCI UART protocol LL registered
Bluetooth: HCI UART protocol Three-wire (H5) registered
RTL871X: module init start
RTL871X: rtl8723bs v4.4.1_17245.20160325_BTCOEX20151223-654a
RTL871X: build time: Nov 18 2017 12:53:39
RTL871X: rtl8723bs BT-Coex version = BTCOEX20151223-654a
RTL871X: hal_com_config_channel_plan chplan:0x21
RTL871X: rtw_ndev_init(wlan0) if1 mac_addr=e0:b9:4d:68:66:1e
RTL871X: module init ret=0
SGI XFS with security attributes, realtime, no debug enabled
UBIFS (ubi0:0): background thread "ubifs_bgt0_0" started, PID 276
NET: Registered protocol family 10
Segment Routing with IPv6
bcmgenet 10430000.ethernet: configuring instance for internal PHY
IPv6: ADDRCONF(NETDEV_UP): eth0: link is not ready
bcmgenet 10430000.ethernet eth0: Link is Up - 100Mbps/Full - flow control rx/tx
IPv6: ADDRCONF(NETDEV_CHANGE): eth0: link becomes ready

STB.

From your dmesg

usb 1-1: new high-speed USB device number 2 using ehci-platform

So from lsusb it recognises it as a USB device.
Bus 001 Device 002: ID 045e:02d5

which is the Xbox/Microsoft module and this is what it expects

https://www.linuxtv.org/wiki/index.php/Xbox_One_Digital_TV_Tuner

Thetuner is the NXP TDA18250 which is supported in Linux from Kernel 4.16 onwards.

There is no mention of the usbcore for dib0700 being registered in your dmesg. You should be seeing

usbcore: registered new interface driver dvb_usb_dib0700

Ok. Just type these at the root in terminal

opkg update
opkg install firmware-dvb-usb-dib0700-1.20
opkg install kernel-module-dvb-usb-dib0700
opkg depends kernel-dvb-usb-dib0700

soporific

I gave that a try without any luck.

root@osmini:~# opkg install firmware-dvb-usb-dib0700-1.20
Package firmware-dvb-usb-dib0700-1.20 (1.0-r0) installed in root is up to date.
root@osmini:~# opkg install kernel-module-dvb-usb-dib0700
Package kernel-module-dvb-usb-dib0700-4.11.0 (4.11-.6) installed in root is up to date.
root@osmini:~# opkg depends kernel-dvb-usb-dib0700

After reboot, no change. Is the problem the kernel in OpenATV (mine is 4.11)?

STB.

soporific wrote: »

I gave that a try without any luck.

root@osmini:~# opkg install firmware-dvb-usb-dib0700-1.20
Package firmware-dvb-usb-dib0700-1.20 (1.0-r0) installed in root is up to date.
root@osmini:~# opkg install kernel-module-dvb-usb-dib0700
Package kernel-module-dvb-usb-dib0700-4.11.0 (4.11-.6) installed in root is up to date.
root@osmini:~# opkg depends kernel-dvb-usb-dib0700

After reboot, no change. Is the problem the kernel in OpenATV (mine is 4.11)?

Perhaps. You did do a hard reboot after install ? ie turn the box on and off at the switch ?

The patch for these is already written.

soporific

Just (hard) rebooted again to make sure - no change.

Thanks STB for the guidance.

I might try and load the latest (unstable) openatv 6.2 image during the week to see if it makes any difference. The kernel is updated. I might even try loading openpli for a test to see if a different kernel makes a difference.

i'll update this thread if i make any progress.

Capt'n Midnight

Dealz have the Xbox One Digital TV Tuner for €6
it's the same Bus 001 Device 003: ID 045e:02d5 as above and no it doesn't work on OpenVix on the Edision OS mini yet


Firmware version: OpenViX 5.1.024 (2018-04-08)
Kernel / Drivers: 4.11.0 / 20171106

https://www.linuxtv.org/wiki/index.php/Xbox_One_Digital_TV_Tuner , Firmware was already on the receiver.

opkg update
opkg install firmware-dvb-usb-dib0700-1.20
opkg install kernel-module-dvb-usb-dib0700
opkg depends kernel-dvb-usb-dib0700

I also Installed this
kernel-module-mn88472-4.11.0 (4.11-.6)
mn88472 kernel module mn88472 kernel module; Panasonic MN88472 DVB-T/T2/C demodulator driver


So as above may just wait for the update to firmware 4.16 for TDA18250 support.

Ardent

Capt'n Midnight wrote: »

Dealz have the Xbox One Digital TV Tuner for €6
it's the same Bus 001 Device 003: ID 045e:02d5 as above and no it doesn't work on OpenVix on the Edision OS mini yet


Firmware version: OpenViX 5.1.024 (2018-04-08)
Kernel / Drivers: 4.11.0 / 20171106

https://www.linuxtv.org/wiki/index.php/Xbox_One_Digital_TV_Tuner , Firmware was already on the receiver.

opkg update
opkg install firmware-dvb-usb-dib0700-1.20
opkg install kernel-module-dvb-usb-dib0700
opkg depends kernel-dvb-usb-dib0700

I also Installed this
kernel-module-mn88472-4.11.0 (4.11-.6)
mn88472 kernel module mn88472 kernel module; Panasonic MN88472 DVB-T/T2/C demodulator driver


So as above may just wait for the update to firmware 4.16 for TDA18250 support.

I picked up this tuner in Dealz today and tried it on my Edison OS mini (Openvix 5.1.030). No joy either.

Will kernel v4.16 arrive any time soon?

STB.

soporific wrote: »

I had a quick look at the linux page for this tuner:
https://www.linuxtv.org/wiki/index.php/Xbox_One_Digital_TV_Tuner

and it seems that it has the dib0700 module which has a driver in enigma

the demodulator (Panasonic MN88472) might prove a problem

Anybody have any ideas?

https://www.linuxtv.org/wiki/index.php/Xbox_One_Digital_TV_Tuner

The demodulator needs firmware. dvb-usb-dib0700-1.20.fw is included in most distributions. The demodulator also needs firmware which is not commonly included. Download it and place in /lib/firmware.

http://palosaari.fi/linux/v4l-dvb/firmware/MN88472/02/latest/dvb-demod-mn88472-02.fw

gkp1

STB. wrote: »

https://www.linuxtv.org/wiki/index.php/Xbox_One_Digital_TV_Tuner

The demodulator needs firmware. dvb-usb-dib0700-1.20.fw is included in most distributions. The demodulator also needs firmware which is not commonly included. Download it and place in /lib/firmware.

http://palosaari.fi/linux/v4l-dvb/firmware/MN88472/02/latest/dvb-demod-mn88472-02.fw

Tried this but still no sign of the tuner appearing. Formuler1 with OpenAtv 6.2. Thanks.

STB.

gkp1 wrote: »

Tried this but still no sign of the tuner appearing. Formuler1 with OpenAtv 6.2. Thanks.

You have also loaded the dib7000 driver from plugins ?

And also the panasonic mn88472 kernel ?

You have hard booted (turned it off and turned it back on ?)

What does dmesg say from telnet ?

It should tell you whats missing.

cat /proc/bus/nim_sockets - will tell you what tuners are loaded

gkp1

STB. wrote: »

https://www.linuxtv.org/wiki/index.php/Xbox_One_Digital_TV_Tuner

The demodulator needs firmware. dvb-usb-dib0700-1.20.fw is included in most distributions. The demodulator also needs firmware which is not commonly included. Download it and place in /lib/firmware.

http://palosaari.fi/linux/v4l-dvb/firmware/MN88472/02/latest/dvb-demod-mn88472-02.fw

STB. wrote: »

You have also loaded the dib7000 driver from plugins ?

And also the panasonic mn88472 kernel ?

You have hard booted (turned it off and turned it back on ?)

What does dmesg say from telnet ?

It should tell you whats missing.

cat /proc/bus/nim_sockets - will tell you what tuners are loaded

I have loaded the dib0700 from plugins

and the panasonic mn88472 kernel and hard rebooted

Command outputs below, Thanks.

root@formuler1:~# cat /proc/bus/nim_sockets
NIM Socket 0:
Type: DVB-S2
Name: BCM7346 (internal)
Has_Outputs: no
Frontend_Device: 0
I2C_Device: 2
NIM Socket 1:
Type: DVB-S2
Name: BCM7346 (internal)
Has_Outputs: no
Frontend_Device: 1
I2C_Device: 1
NIM Socket 2:
Type: DVB-T2
Name: Si2168
Has_Outputs: yes
Frontend_Device: 2
I2C_Device: 1
root@formuler1:~#



root@formuler1:~# dmesg
[ 0.060000] Key type id_legacy registered
[ 0.060000] nfs4filelayout_init: NFSv4 File Layout Driver Registering...
[ 0.060000] Installing knfsd (copyright (C) 1996 okir@monad.swb.de).
[ 0.060000] FS-Cache: Netfs 'cifs' registered for caching
[ 0.060000] Key type cifs.spnego registered
[ 0.060000] fuse init (API version 7.26)
[ 0.066000] Block layer SCSI generic (bsg) driver version 0.4 loaded (major 253)
[ 0.066000] io scheduler noop registered
[ 0.067000] io scheduler cfq registered (default)
[ 0.067000] Serial: 8250/16550 driver, 4 ports, IRQ sharing disabled
[ 0.068000] serial8250.0: ttyS0 at MMIO 0x10406900 (irq = 65, base_baud = 5062500) is a 16550A
[ 0.068000] serial8250.0: ttyS1 at MMIO 0x10406940 (irq = 66, base_baud = 5062500) is a 16550A
[ 0.069000] serial8250.0: ttyS2 at MMIO 0x10406980 (irq = 67, base_baud = 5062500) is a 16550A
[ 0.076000] loop: module loaded
[ 0.076000] ahci ahci.0: SSS flag set, parallel bus scan disabled
[ 0.086000] ahci ahci.0: AHCI 0001.0300 32 slots 3 ports 6 Gbps 0x3 impl platform mode
[ 0.086000] ahci ahci.0: flags: ncq sntf stag clo pmp slum part
[ 0.091000] scsi host0: ahci
[ 0.092000] scsi host1: ahci
[ 0.092000] scsi host2: ahci
[ 0.092000] ata1: FORCE: PHY spd limit set to 3.0Gbps
[ 0.092000] ata1: SATA max UDMA/133 mmio [mem 0x10181000-0x10190fff] port 0x100 irq 41
[ 0.092000] ata2: FORCE: PHY spd limit set to 3.0Gbps
[ 0.092000] ata2: SATA max UDMA/133 mmio [mem 0x10181000-0x10190fff] port 0x180 irq 41
[ 0.092000] ata3: DUMMY
[ 0.093000] brcmstb_nand: NAND controller driver is loaded
[ 0.093000] libphy: Fixed MDIO Bus: probed
[ 0.093000] __clk_enable: network [1]
[ 0.093000] __clk_enable: enet [1]
[ 0.093000] bcm40nm_pm_genet_enable 00
[ 0.093000] bcmgenet bcmgenet.0: GENET 2.9 EPHY: 0x00b0
[ 0.093000] bcmgenet bcmgenet.0: failed to get enet-eee clock
[ 0.405000] ata1: SATA link down (SStatus 0 SControl 320)
[ 0.709000] ata2: SATA link down (SStatus 0 SControl 320)
[ 0.788000] libphy: bcmgenet MII bus: probed
[ 0.788000] __clk_disable: enet [0]
[ 0.788000] bcm40nm_pm_genet_disable 00
[ 0.788000] __clk_disable: network [0]
[ 0.788000] ehci_hcd: USB 2.0 'Enhanced' Host Controller (EHCI) Driver
[ 0.788000] __clk_enable: usb [1]
[ 0.788000] bcm40nm_pm_usb_enable 00
[ 0.788000] ehci-brcm ehci-brcm.0: Broadcom STB EHCI
[ 0.788000] ehci-brcm ehci-brcm.0: new USB bus registered, assigned bus number 1
[ 0.799000] ehci-brcm ehci-brcm.0: irq 69, io mem 0x10480300
[ 0.806000] ehci-brcm ehci-brcm.0: USB 0.0 started, EHCI 1.00
[ 0.806000] hub 1-0:1.0: USB hub found
[ 0.806000] hub 1-0:1.0: 1 port detected
[ 0.807000] ehci-brcm ehci-brcm.1: Broadcom STB EHCI
[ 0.807000] ehci-brcm ehci-brcm.1: new USB bus registered, assigned bus number 2
[ 0.817000] ehci-brcm ehci-brcm.1: irq 70, io mem 0x10480500
[ 0.824000] ehci-brcm ehci-brcm.1: USB 0.0 started, EHCI 1.00
[ 0.824000] hub 2-0:1.0: USB hub found
[ 0.824000] hub 2-0:1.0: 1 port detected
[ 0.825000] ehci-brcm ehci-brcm.2: Broadcom STB EHCI
[ 0.825000] ehci-brcm ehci-brcm.2: new USB bus registered, assigned bus number 3
[ 0.835000] ehci-brcm ehci-brcm.2: irq 74, io mem 0x10490300
[ 0.842000] ehci-brcm ehci-brcm.2: USB 0.0 started, EHCI 1.00
[ 0.842000] hub 3-0:1.0: USB hub found
[ 0.842000] hub 3-0:1.0: 1 port detected
[ 0.843000] ehci-brcm ehci-brcm.3: Broadcom STB EHCI
[ 0.843000] ehci-brcm ehci-brcm.3: new USB bus registered, assigned bus number 4
[ 0.853000] ehci-brcm ehci-brcm.3: irq 75, io mem 0x10490500
[ 0.860000] ehci-brcm ehci-brcm.3: USB 0.0 started, EHCI 1.00
[ 0.860000] hub 4-0:1.0: USB hub found
[ 0.860000] hub 4-0:1.0: 1 port detected
[ 0.861000] ohci_hcd: USB 1.1 'Open' Host Controller (OHCI) Driver
[ 0.861000] ohci-brcm ohci-brcm.0: Broadcom STB OHCI
[ 0.861000] ohci-brcm ohci-brcm.0: new USB bus registered, assigned bus number 5
[ 0.861000] ohci-brcm ohci-brcm.0: irq 71, io mem 0x10480400
[ 0.927000] hub 5-0:1.0: USB hub found
[ 0.927000] hub 5-0:1.0: 1 port detected
[ 0.928000] ohci-brcm ohci-brcm.1: Broadcom STB OHCI
[ 0.928000] ohci-brcm ohci-brcm.1: new USB bus registered, assigned bus number 6
[ 0.928000] ohci-brcm ohci-brcm.1: irq 72, io mem 0x10480600
[ 0.994000] hub 6-0:1.0: USB hub found
[ 0.994000] hub 6-0:1.0: 1 port detected
[ 0.995000] ohci-brcm ohci-brcm.2: Broadcom STB OHCI
[ 0.995000] ohci-brcm ohci-brcm.2: new USB bus registered, assigned bus number 7
[ 0.995000] ohci-brcm ohci-brcm.2: irq 76, io mem 0x10490400
[ 1.061000] hub 7-0:1.0: USB hub found
[ 1.061000] hub 7-0:1.0: 1 port detected
[ 1.062000] ohci-brcm ohci-brcm.3: Broadcom STB OHCI
[ 1.062000] ohci-brcm ohci-brcm.3: new USB bus registered, assigned bus number 8
[ 1.062000] ohci-brcm ohci-brcm.3: irq 77, io mem 0x10490600
[ 1.128000] hub 8-0:1.0: USB hub found
[ 1.128000] hub 8-0:1.0: 1 port detected
[ 1.129000] usbcore: registered new interface driver uas
[ 1.129000] usbcore: registered new interface driver usb-storage
[ 1.129000] mousedev: PS/2 mouse device common for all mice
[ 1.129000] i2c /dev entries driver
[ 1.129000] usbcore: registered new interface driver btusb
[ 1.130000] sdhci: Secure Digital Host Controller Interface driver
[ 1.130000] sdhci: Copyright(c) Pierre Ossman
[ 1.130000] sdhci-pltfm: SDHCI platform and OF driver helper
[ 1.130000] sdhci-brcmstb sdhci-brcmstb.0: Enabling controller
[ 1.130000] mmc0: Failed to set 32-bit DMA mask.
[ 1.130000] mmc0: No suitable DMA available - falling back to PIO
[ 1.162000] mmc0: SDHCI controller on sdhci-brcmstb.0 [sdhci-brcmstb.0] using PIO
[ 1.162000] hidraw: raw HID events driver (C) Jiri Kosina
[ 1.162000] usbcore: registered new interface driver usbhid
[ 1.162000] usbhid: USB HID core driver
[ 1.163000] NET: Registered protocol family 17
[ 1.163000] Bluetooth: HIDP (Human Interface Emulation) ver 1.2
[ 1.163000] Bluetooth: HIDP socket layer initialized
[ 1.163000] Key type dns_resolver registered
[ 1.163000] PM: CP0 COUNT/COMPARE frequency does not depend on divisor
[ 1.164000] EBI CS0: setting up NAND flash (primary)
[ 1.164000] nand: device found, Manufacturer ID: 0xad, Chip ID: 0xdc
[ 1.164000] nand: Hynix H27U4G8F2DTR-BC
[ 1.164000] nand: 512 MiB, SLC, erase size: 128 KiB, page size: 2048, OOB size: 64
[ 1.165000] nand: device found, Manufacturer ID: 0xad, Chip ID: 0xdc
[ 1.165000] nand: Hynix H27U4G8F2DTR-BC
[ 1.165000] nand: 512 MiB, SLC, erase size: 128 KiB, page size: 2048, OOB size: 64
[ 1.165000] brcmnand brcmnand.0: 512MiB total, 128KiB blocks, 2KiB pages, 16B OOB, 8-bit, Hamming ECC
[ 1.165000] Bad block table found at page 262080, version 0x01
[ 1.166000] Bad block table found at page 262016, version 0x01
[ 1.166000] nand_read_bbt: bad block at 0x000006880000
[ 1.166000] nand_read_bbt: bad block at 0x0000068a0000
[ 1.166000] nand_read_bbt: bad block at 0x0000068c0000
[ 1.166000] nand_read_bbt: bad block at 0x0000068e0000
[ 1.166000] nand_read_bbt: bad block at 0x000006900000
[ 1.166000] nand_read_bbt: bad block at 0x000006920000
[ 1.166000] nand_read_bbt: bad block at 0x000008b80000
[ 1.166000] nand_read_bbt: bad block at 0x000008bc0000
[ 1.166000] nand_read_bbt: bad block at 0x000008c00000
[ 1.166000] nand_read_bbt: bad block at 0x000008c40000
[ 1.166000] nand_read_bbt: bad block at 0x00000e1e0000
[ 1.167000] Creating 3 MTD partitions on "brcmnand.0":
[ 1.167000] 0x000000500000-0x000020000000 : "complete"
[ 1.171000] 0x000000500000-0x000000b00000 : "kernel"
[ 1.172000] 0x000000b00000-0x000020000000 : "rootfs"
[ 1.176000] ubi0: default fastmap pool size: 200
[ 1.176000] ubi0: default fastmap WL pool size: 100
[ 1.176000] ubi0: attaching mtd2
[ 1.267000] usb 3-1: new high-speed USB device number 2 using ehci-brcm
[ 1.358000] usb 6-1: new full-speed USB device number 2 using ohci-brcm
[ 1.523000] ubi0: attached by fastmap
[ 1.523000] ubi0: fastmap pool size: 200
[ 1.523000] ubi0: fastmap WL pool size: 100
[ 1.537000] ubi0: attached mtd2 (name "rootfs", size 501 MiB)
[ 1.537000] ubi0: PEB size: 131072 bytes (128 KiB), LEB size: 126976 bytes
[ 1.537000] ubi0: min./max. I/O unit sizes: 2048/2048, sub-page size 2048
[ 1.537000] ubi0: VID header offset: 2048 (aligned 2048), data offset: 4096
[ 1.537000] ubi0: good PEBs: 3993, bad PEBs: 15, corrupted PEBs: 0
[ 1.537000] ubi0: user volume: 1, internal volumes: 1, max. volumes count: 128
[ 1.537000] ubi0: max/mean erase counter: 14/6, WL threshold: 4096, image sequence number: 1704770225
[ 1.537000] ubi0: available PEBs: 0, total reserved PEBs: 3993, PEBs reserved for bad PEB handling: 65
[ 1.537000] ubi0: background thread "ubi_bgt0d" started, PID 89
[ 1.537000] ALSA device list:
[ 1.537000] No soundcards found.
[ 1.537000] Warning: unable to open an initial console.
[ 1.539000] UBIFS (ubi0:0): background thread "ubifs_bgt0_0" started, PID 90
[ 1.659000] UBIFS (ubi0:0): UBIFS: mounted UBI device 0, volume 0, name "rootfs"
[ 1.659000] UBIFS (ubi0:0): LEB size: 126976 bytes (124 KiB), min./max. I/O unit sizes: 2048 bytes/2048 bytes
[ 1.659000] UBIFS (ubi0:0): FS size: 496603136 bytes (473 MiB, 3911 LEBs), journal size 9023488 bytes (8 MiB, 72 LEBs)
[ 1.659000] UBIFS (ubi0:0): reserved for root: 0 bytes (0 KiB)
[ 1.659000] UBIFS (ubi0:0): media format: w4/r0 (latest is w5/r0), UUID BC48E047-03FD-4EFC-9417-AF05705221A9, small LPT model
[ 1.661000] VFS: Mounted root (ubifs filesystem) on device 0:12.
[ 1.662000] devtmpfs: mounted
[ 1.663000] Freeing unused kernel memory: 276K
[ 1.663000] This architecture does not have kernel memory protection.
[ 1.845000] random: crng init done
[ 2.016000] usb 1-1: new high-speed USB device number 2 using ehci-brcm
[ 2.138000] scsi host3: uas
[ 2.140000] scsi 3:0:0:0: Direct-Access Seagate BUP Slim RD 0304 PQ: 0 ANSI: 6
[ 2.150000] sd 3:0:0:0: Attached scsi generic sg0 type 0
[ 2.150000] sd 3:0:0:0: [sda] Spinning up disk...
[ 2.566000] formuler1_1: module_layout: kernel tainted.
[ 2.566000] Disabling lock debugging due to kernel taint
[ 2.566000] formuler1_1: loading out-of-tree module taints kernel.
[ 2.570000] usbcore: registered new interface driver tpm
[ 3.168000] .
[ 4.193000] .
[ 4.193000] ready
[ 4.194000] sd 3:0:0:0: [sda] 1953525167 512-byte logical blocks: (1.00 TB/932 GiB)
[ 4.194000] sd 3:0:0:0: [sda] 2048-byte physical blocks
[ 4.224000] sd 3:0:0:0: [sda] Write Protect is off
[ 4.224000] sd 3:0:0:0: [sda] Mode Sense: 4f 00 00 00
[ 4.225000] sd 3:0:0:0: [sda] Write cache: enabled, read cache: enabled, doesn't support DPO or FUA
[ 4.260000] sda: sda1
[ 4.264000] sd 3:0:0:0: [sda] Attached SCSI disk
[ 5.337000] EXT4-fs (sda1): mounted filesystem with writeback data mode. Opts: (null)
[ 8.068000] input: dreambox remote control (native) as /devices/virtual/input/input0
[ 8.069000] input: dreambox advanced remote control (native) as /devices/virtual/input/input1
[ 8.145000] dvbdev: DVB: registering new adapter (dvb0)
[ 8.147000] platform dvb0.0: DVB: registering adapter 0 frontend 0 (DVB-S2)...
[ 8.156000] platform dvb0.0: DVB: registering adapter 0 frontend 1 (DVB-S2)...
[ 8.157000] platform dvb0.0: DVB: registering adapter 0 frontend 2 (DVB-T/T2/C)...
[ 8.472000] input: front panel as /devices/virtual/input/input2
[ 8.531000] Registered IR keymap rc-cec
[ 8.531000] input: RC for hdmi_cec as /devices/platform/hdmi.0/rc/rc0/input3
[ 8.532000] rc rc0: RC for hdmi_cec as /devices/platform/hdmi.0/rc/rc0
[ 8.839000] SGI XFS with security attributes, realtime, no debug enabled
[ 8.881000] boxmodel: module license 'proprietary' taints kernel.
[ 11.855000] NET: Registered protocol family 10
[ 11.856000] Segment Routing with IPv6
[ 12.169000] __clk_enable: network [1]
[ 12.169000] __clk_enable: enet [1]
[ 12.169000] bcm40nm_pm_genet_enable 00
[ 12.293000] bcmgenet bcmgenet.0: configuring instance for external RGMII (TX delay)
[ 12.293000] IPv6: ADDRCONF(NETDEV_UP): eth0: link is not ready
[ 13.474000] bcmgenet bcmgenet.0 eth0: Link is Down
[ 16.749000] bcmgenet bcmgenet.0 eth0: Link is Up - 1Gbps/Full - flow control rx/tx
[ 16.749000] IPv6: ADDRCONF(NETDEV_CHANGE): eth0: link becomes ready
root@formuler1:~#

STB.

@gkp1. There is absolutely nothing installed there from that log to do with the usb dvb-t device. You'd have the errors galore showing or at least the "state" the device is loaded in.


Would you try removing the drivers and load again. You can do it from telnet. Do an opkg update and install the driver and dependancies.


opkg install enigma2-plugin-drivers-dvb-usb-dib0700
opkg -force-depends kernel-module-dvb-usb-dib0700


See if it works (watch for the "Collected errors") as I guess it will look for the .fw file that goes in /lib/firmware (linked earlier)

http://palosaari.fi/linux/v4l-dvb/firmware/MN88472/02/latest/

If that dont work...... Theres a guy who wrote the patch

gkp1

STB. wrote: »

@gkp1. There is absolutely nothing installed there from that log to do with the usb dvb-t device. You'd have the errors galore showing or at least the "state" the device is loaded in.


Would you try removing the drivers and load again. You can do it from telnet. Do an opkg update and install the driver and dependancies.


opkg install enigma2-plugin-drivers-dvb-usb-dib0700
opkg -force-depends kernel-module-dvb-usb-dib0700


See if it works (watch for the "Collected errors") as I guess it will look for the .fw file that goes in /lib/firmware (linked earlier)

http://palosaari.fi/linux/v4l-dvb/firmware/MN88472/02/latest/

If that dont work...... Theres a guy who wrote the patch

Sorry my linux knowledge is weak. Removed the drivers, did the update and install, the depends seems to fail on syntax?

root@formuler1:~# opkg update
Downloading http://feeds2.mynonpublic.com/6.2/formuler1/3rdparty/Packages.gz.
Updated source 'openatv-3rdparty'.
Downloading http://feeds2.mynonpublic.com/6.2/formuler1/all/Packages.gz.
Updated source 'openatv-all'.
Downloading http://feeds2.mynonpublic.com/6.2/formuler1/formuler1/Packages.gz.
Updated source 'openatv-formuler1'.
Downloading http://feeds2.mynonpublic.com/6.2/formuler1/formuler1_3rdparty/Packages.gz.
Updated source 'openatv-formuler1_3rdparty'.
Downloading http://feeds2.mynonpublic.com/6.2/formuler1/mips32el/Packages.gz.
Updated source 'openatv-mips32el'.
root@formuler1:~#

root@formuler1:~# opkg install enigma2-plugin-drivers-dvb-usb-dib0700
enigma2-plugin-drivers-dvb-usb-dib0700: unsatisfied recommendation for kernel-module-tda18250
enigma2-plugin-drivers-dvb-usb-dib0700: unsatisfied recommendation for kernel-module-tuner-xc2028
Installing firmware-dvb-usb-dib0700-1.20 (1.0) on root.
Downloading http://feeds2.mynonpublic.com/6.2/formuler1/all/firmware-dvb-usb-dib0700-1.20_1.0-r0_all.ipk.
Installing firmware-dvb-usb-dibusb-5.0.0.11 (1.0) on root.
Downloading http://feeds2.mynonpublic.com/6.2/formuler1/all/firmware-dvb-usb-dibusb-5.0.0.11_1.0-r0_all.ipk.
Installing firmware-dvb-usb-dibusb-6.0.0.8 (1.0) on root.
Downloading http://feeds2.mynonpublic.com/6.2/formuler1/all/firmware-dvb-usb-dibusb-6.0.0.8_1.0-r0_all.ipk.
Installing firmware-dvb-usb-dibusb-an2235-01 (1.0) on root.
Downloading http://feeds2.mynonpublic.com/6.2/formuler1/all/firmware-dvb-usb-dibusb-an2235-01_1.0-r0_all.ipk.
Installing firmware-mn8847x (1.0) on root.
Downloading http://feeds2.mynonpublic.com/6.2/formuler1/all/firmware-mn8847x_1.0-r0_all.ipk.
Installing firmware-xc3028-v27 (1.0) on root.
Downloading http://feeds2.mynonpublic.com/6.2/formuler1/all/firmware-xc3028-v27_1.0-r0_all.ipk.
Installing firmware-xc3028l-v36 (1.0) on root.
Downloading http://feeds2.mynonpublic.com/6.2/formuler1/all/firmware-xc3028l-v36_1.0-r0_all.ipk.
Installing kernel-module-dib3000mb-4.10.6 (4.10.6) on root.
Downloading http://feeds2.mynonpublic.com/6.2/formuler1/formuler1/kernel-module-dib3000mb-4.10.6_4.10.6-.5_formuler1.ipk.
Installing kernel-module-dib7000p-4.10.6 (4.10.6) on root.
Downloading http://feeds2.mynonpublic.com/6.2/formuler1/formuler1/kernel-module-dib7000p-4.10.6_4.10.6-.5_formuler1.ipk.
Installing kernel-module-dib8000-4.10.6 (4.10.6) on root.
Downloading http://feeds2.mynonpublic.com/6.2/formuler1/formuler1/kernel-module-dib8000-4.10.6_4.10.6-.5_formuler1.ipk.
Installing kernel-module-dvb-usb-dib0700-4.10.6 (4.10.6) on root.
Downloading http://feeds2.mynonpublic.com/6.2/formuler1/formuler1/kernel-module-dvb-usb-dib0700-4.10.6_4.10.6-.5_formuler1.ipk.
Installing kernel-module-dvb-usb-dibusb-mc-4.10.6 (4.10.6) on root.
Downloading http://feeds2.mynonpublic.com/6.2/formuler1/formuler1/kernel-module-dvb-usb-dibusb-mc-4.10.6_4.10.6-.5_formuler1.ipk.
Installing kernel-module-fc0013-4.10.6 (4.10.6) on root.
Downloading http://feeds2.mynonpublic.com/6.2/formuler1/formuler1/kernel-module-fc0013-4.10.6_4.10.6-.5_formuler1.ipk.
Installing kernel-module-mn88472-4.10.6 (4.10.6) on root.
Downloading http://feeds2.mynonpublic.com/6.2/formuler1/formuler1/kernel-module-mn88472-4.10.6_4.10.6-.5_formuler1.ipk.
Installing kernel-module-mt2060-4.10.6 (4.10.6) on root.
Downloading http://feeds2.mynonpublic.com/6.2/formuler1/formuler1/kernel-module-mt2060-4.10.6_4.10.6-.5_formuler1.ipk.
Installing kernel-module-mt2266-4.10.6 (4.10.6) on root.
Downloading http://feeds2.mynonpublic.com/6.2/formuler1/formuler1/kernel-module-mt2266-4.10.6_4.10.6-.5_formuler1.ipk.
Installing enigma2-plugin-drivers-dvb-usb-dib0700 (1.0) on root.
Downloading http://feeds2.mynonpublic.com/6.2/formuler1/all/enigma2-plugin-drivers-dvb-usb-dib0700_1.0-r0_all.ipk.
Configuring firmware-xc3028l-v36.
Configuring kernel-module-dib8000-4.10.6.
Configuring kernel-module-dvb-usb-dibusb-mc-4.10.6.
Configuring kernel-module-dib7000p-4.10.6.
Configuring firmware-mn8847x.
Configuring kernel-module-mt2266-4.10.6.
Configuring firmware-dvb-usb-dibusb-an2235-01.
Configuring kernel-module-mn88472-4.10.6.
Configuring kernel-module-mt2060-4.10.6.
Configuring firmware-dvb-usb-dib0700-1.20.
Configuring firmware-xc3028-v27.
Configuring kernel-module-fc0013-4.10.6.
Configuring firmware-dvb-usb-dibusb-6.0.0.8.
Configuring firmware-dvb-usb-dibusb-5.0.0.11.
Configuring kernel-module-dib3000mb-4.10.6.
Configuring kernel-module-dvb-usb-dib0700-4.10.6.
Configuring enigma2-plugin-drivers-dvb-usb-dib0700.

root@formuler1:~# opkg -force-depends kernel-module-dvb-usb-dib0700
opkg: unknown sub-command kernel-module-dvb-usb-dib0700
usage: opkg [options...] sub-command [arguments...]

STB.

gkp1 wrote: »

Sorry my linux knowledge is weak. Removed the drivers, did the update and install, the depends seems to fail on syntax?

root@formuler1:~# opkg install enigma2-plugin-drivers-dvb-usb-dib0700
enigma2-plugin-drivers-dvb-usb-dib0700: unsatisfied recommendation for kernel-module-tda18250
enigma2-plugin-drivers-dvb-usb-dib0700: unsatisfied recommendation for kernel-module-tuner-xc2028

AND

root@formuler1:~# opkg -force-depends kernel-module-dvb-usb-dib0700
opkg: unknown sub-command kernel-module-dvb-usb-dib0700
usage: opkg [options...] sub-command [arguments...]

This is openatv's feeds (from the nonpublic address) I wonder are they missing modules on the formuler 1 for dib700. Like the "kernel-module-tuner-xc2028" and tda18250 is missing.

Yeah I saw the syntax like error for the force depends. I'm no guru myself.

Okay one final time and after that you may try talking to openatv or switch to openvix or even better openpli - they actually fix driver stuff https://openpli.org/download/formuler/F1/.

opkg install kernel-module-dvb-usb-dib0700
opkg files kernel-module-dvb-usb-dib0700
opkg depends kernel-module-dvb-usb-dib0700

And reboot.

gkp1

STB. wrote: »

This is openatv's feeds (from the nonpublic address) I wonder are they missing modules on the formuler 1 for dib700. Like the "kernel-module-tuner-xc2028" and tda18250 is missing.

Yeah I saw the syntax like error for the force depends. I'm no guru myself.

Okay one final time and after that you may try talking to openatv or switch to openvix or even better openpli - they actually fix driver stuff https://openpli.org/download/formuler/F1/.

opkg install kernel-module-dvb-usb-dib0700
opkg files kernel-module-dvb-usb-dib0700
opkg depends kernel-module-dvb-usb-dib0700

And reboot.

All commands run successfully but no sign of tuner after reboot and nothing showing in dmesg output. As you say it is probably time to move on and try some different options. Thanks again.

gkp1

gkp1 wrote: »

All commands run successfully but no sign of tuner after reboot and nothing showing in dmesg output. As you say it is probably time to move on and try some different options. Thanks again.

Ordered Tuner USB 2.0 3.0 DAB FM DONGLE STICK DIGITAL TV RTL2832U R820T SDR from ebay, plugged in, installed driver and it works perfectly. (OpenATV 6.2 on Formuler1).

Capt'n Midnight

BTW
OpenVix 5.2 still uses the 4.11.0 Kernel so 4.16 may be a while away

Firmware version: OpenViX 5.2.001 (2018-09-24)
Kernel / Drivers: 4.11.0 / 20171106

JDxtra

Capt'n Midnight wrote: »

BTW
OpenVix 5.2 still uses the 4.11.0 Kernel so 4.16 may be a while away

Firmware version: OpenViX 5.2.001 (2018-09-24)
Kernel / Drivers: 4.11.0 / 20171106

Current version of OpenVIX uses kernel 4.1.20. The Xbox USB tuner detected fine for me once I loaded the driver from plugins and restarted.

Ardent

JDxtra wrote: »

Current version of OpenVIX uses kernel 4.1.20. The Xbox USB tuner detected fine for me once I loaded the driver from plugins and restarted.

What version of OpenVix is that and for what device?

(I downloaded the very latest for my Edison OS Mini and unfortunately it's 5.2.030 with a kernel of 4.11.0)

JDxtra

Ardent wrote: »

What version of OpenVix is that and for what device?

(I downloaded the very latest for my Edison OS Mini and unfortunately it's 5.2.030 with a kernel of 4.11.0)

OpenVIX 5.2.029 for the VU+ Zero 4K.

JDxtra

Also just checked it on my Gigablue UHD UE 4K and it was detected there also (see attached).

tommycahir

Does anyone know if the xbox tuner will work with openatv 6.2 on Mutant hd51 or hd1500 or zgemma h2s?

STB.

JDxtra wrote: »

OpenVIX 5.2.029 for the VU+ Zero 4K.

Entry in the log


backport some dvb tuner (xbox one, terratech h7, hama-hyrid,s2870, xtratv, wintv-solo4k) on linux 4.x

Capt'n Midnight

STB. wrote: »

Entry in the log


backport some dvb tuner (xbox one, terratech h7, hama-hyrid,s2870, xtratv, wintv-solo4k) on linux 4.x

Some more back ports on updates now to support Microsoft Xbox one Digital TV Tuner .
multibox et1x000 ultramini 9900lx sf4008 broadmedia


5.0.034 updates aren't loading for me on 5.0.033 so I may wait for the image

ldap

I’ve a Gigablue X3 4K that I’m trying to get 2 Xbox DVBT dongles working with. I’ve tried OpenATV 6.4 and 7 (beta) and have failed to get any channels on both systems. Same with the teamblue flavour of enigma. I suspect it’s something to do with the h.264 encoding that Saorview uses. I can install the drivers for the usb tuner and it’s definitely picking up something when it hits both muxes in my area but it still won’t show me any channels.

Running dmesg | grep dvb gives me this

[   3.120803] dvb-usb: found a 'Microsoft Xbox One Digital TV Tuner' in cold state, will try to load a firmware

[   3.136807] dvb-usb: downloading firmware from file 'dvb-usb-dib0700-1.20.fw'

[   3.863278] dvb-usb: found a 'Microsoft Xbox One Digital TV Tuner' in warm state.

[   3.870991] dvb-usb: will pass the complete MPEG2 transport stream to the software demuxer.

[   4.098328] dvb-usb: Microsoft Xbox One Digital TV Tuner successfully initialized and connected.

[   4.107503] usbcore: registered new interface driver dvb_usb_dib0700

(omitting a load of satellite stuff that’s irrelevant)

[   16.942819] mn88472 0-0018: downloading firmware from file 'dvb-demod-mn88472-02.fw'

[   17.115697] dvb dvb.0: DVB: registering adapter 0 frontend 0 (Xbox USB Tuner)...

MPEG2 TS is making me think that it might be the issue but I don’t understand the last bit either. Any help would be appreciated.

krisux

https://www.boards.ie/discussion/comment/118404051#Comment_118404051

i have exactly the same problem on gigablue ue 4k. Have you solved the problem?
